Vector SX-122 Series
The Spectrumtek Vector SX-122 is a professional 5-inch tri-beam LED pod light pair engineered to eliminate dangerous A-pillar blind spots. Powered by premium Osram P8 + ZES dual-chip technology, this 122W pair delivers 270° peripheral coverage alongside a focused long-range forward driving beam. With IP68/IP69K dual waterproof certification, a military-grade breather valve, and comprehensive electrical protection, the Vector SX-122 is built for serious off-road, expedition, and competition use in the UK and Europe.
• Revolutionary 270° Tri-Beam: Forward driving beam + 270° peripheral array eliminates A-pillar blind spots
• Osram P8 + ZES Dual-Chip Technology: Premium German-engineered LEDs trusted by Mercedes-Benz, BMW, and Audi
• 122W Pair Output (61W per light): Professional-grade power with 80+ lumens/watt efficiency
• IP68/IP69K Dual Certified: Complete submersion (1.5m) and 100-bar high-pressure wash protection
• Military-Grade Breather Valve: Prevents internal condensation through pressure equalisation
• Polarity Reversal Protection: MOSFET-based system blocks damage from incorrect wiring instantly
• Overvoltage Protection: Guards against alternator load dump, jump-start spikes across 9–32V
• Vibration Resistant Engineering: Shock-mounted components tested to 25G peak for off-road use
• Aluminium Cooling Fins: Integrated thermal management for 50,000+ hour LED lifespan
• Universal 9–32V DC: Compatible with 12V and 24V vehicle systems
• CE, RoHS & EMC Certified: Full UK and European compliance
• 24-Month Manufacturer Warranty
Performance Metric
Specification
Total Power (Pair)
122W (61W per light)
LED Technology
Osram P8 + ZES Dual-Chip
Luminous Efficiency
80+ Lumens per Watt
Colour Temperature
6000K Cool White
Beam Pattern
Tri-Beam: Forward Drive + 270° Peripheral
Peripheral Coverage
270° (135° left + 135° right)
Waterproof Rating
IP68 (1.5m) + IP69K (100-bar)
Operating Temperature
-40°C to +85°C
LED Lifespan
50,000+ Hours (>80% output retention)
Specification
Value
Model
Vector SX-122
Configuration
Sold as Pair (2 Lights)
Physical Size
5-Inch (127mm) per light
Total Power
122W Pair / 61W per Light
Operating Voltage
9–32V DC Universal
Current Draw @ 12V
~10.2A (pair)
Current Draw @ 24V
~5.1A (pair)
Housing Material
Die-Cast Aluminium Alloy
Lens Material
PC Polycarbonate (250× glass strength)
Breather System
Military-Grade Pressure Equalisation Valve
Connector
Waterproof DT Connector (pre-installed)
Polarity Protection
Yes — Integrated MOSFET
Overload Protection
Yes — Automatic Circuitry
Overvoltage Protection
Yes — Surge & Spike Protection
Vibration Resistant
Yes — 25G peak tested
Weight (Pair)
Approx. 1.2 kg
Certifications
CE | RoHS | EMC | IP68 | IP69K
Warranty
24-Month Manufacturer Warranty
Military-Grade Breather Valve
The Vector SX-122 incorporates a military-specification breather valve that equalises internal pressure caused by thermal cycling across its -40°C to +85°C operating range. As the housing heats and cools during 122W dual-chip operation, the valve permits controlled air exchange while blocking moisture, dust, and contaminants—preventing seal fatigue and internal condensation. Rated to MIL-STD standards, it preserves full IP68/IP69K waterproof integrity through submersion and 100-bar high-pressure washing.
Polarity Reversal, Overvoltage & Vibration Protection
Integrated MOSFET polarity reversal protection responds in microseconds to prevent damage from incorrect wiring—the most common installation error. Overvoltage protection guards against alternator load dump spikes and jump-start transients across the full 9–32V range, safeguarding premium Osram P8 and ZES drivers. Shock-mounted construction with die-cast aluminium housing is vibration-tested to 25G peak, ensuring reliable 270° tri-beam performance in rock crawling, desert racing, and agricultural environments.
• Off-Road & Competition: Rock crawling, desert racing, technical trails
• Expedition & Overland: Long-range adventure, remote-area exploration
• Agricultural & Commercial: Tractors, HGVs, site vehicles, fleet
• Emergency Services: Search and rescue, recovery operations
24-month manufacturer warranty covering both lights. UK-based support from Spectrumtek’s experienced LED engineering team.
